Medical Tube Automatic Coiling and Packaging Machine Suction Connecting Tube Winding And Packing Equipment XYG001

  • Medical Tube Automatic Coiling and Packaging Machine Suction Connecting Tube Winding And Packing Equipment XYG001
  • Medical Tube Automatic Coiling and Packaging Machine Suction Connecting Tube Winding And Packing Equipment XYG001
  • Medical Tube Automatic Coiling and Packaging Machine Suction Connecting Tube Winding And Packing Equipment XYG001
Place of Origin Jiangsu, China
Brand Name Jiezhicheng
Model Number JZC-XYG001
Minimum Order Quantity 1
Price Negtiable
Packaging Details Negotiable
Delivery Time 90-120 days
Payment Terms Western Union
Supply Ability 10 sets per 120 days
Product Details
Diameter 0.5mm Production Speed Up To 100 Packages Per Minute
Applicable Pipe Nasal Oxygen Tube Plastic Tube Power Specification 80-300mm
Automation Level Fully Automated / Semi-Automated Operationmode Semi-automatic / Fully Automatic
Dimensions Customizable Sealingmethod Heat Sealing / Ultrasonic Sealing
Tube Chief 210mm Production Beat 9S Released 2 Products
Safety Features Emergency Stop Button And Safety Guards Bearing NSK
Speed 100-150 Bags/min Packagingspeed Up To 60 Packages Per Minute
Film Width 80-350mm
Leave a Message
Product Description

Product description:

Medical Tube Automatic Coiling and Packaging Machine Suction Connecting Tube Winding And Packing Equipment XYG001

Medical Tube Automatic Coiling and Packaging Machine Suction Connecting Tube Winding And Packing Equipment XYG001 0

Medical Tube Automatic Coiling and Packaging Machine Suction Connecting Tube Winding And Packing Equipment XYG001 1

Equipment function:

1. The machine can automatically coil, fill inner bag and outer bag and seal;

2. Adopt cylinder translation drive mode, the displacement is more accurate;

3. One person can operate the machine in a one cut of two way;

4. Production speed: 7s/ 2pcs.



Technical parameters:

1. Weight: 550 kg;

2. Size: 5.4*2.3*1.7m;

3. Voltage: AC 220V single-phrase three-wire system;

4. Feeding mode: The inner and outer bags are automatic feeding.



Configuration instruction:

1. Pneumatic components: SMS cylinder;

2. Operation interface: Omron;

3 Electric PLC: Omron;

4. Sensor: Otis, Japan;

5. Servo motor: Yaskawa motor;

6. Line track: HIWIN, Taiwan;

7. Bearing: NSK Japan.



Scope of application:

Automatic production equipment for packaging and sealing of nasal oxygen tube, suction tube an other medical tube coil, automatic assembly and packaging of medical consumables can be customized.
